Ford Focus III (2011-2015) vehicle audio signal for pedestrian Wiring diagrams
This page contains all the electrical diagrams for the component. vehicle audio signal for pedestrian, in which he is found in the car Ford Focus III (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
vehicle audio signal for pedestrian wiring diagram (1 of 2)
AIR CONDITIONING CONTROL MODULE
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
ANTI-THEFT HOOD SWITCH
BATTERY
BATTERY MONITORING SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL POSITION (BPP) SWITCH
CHARGE PORT LIGHT RING
COOLANT VALVE 1
COOLANT VALVE 2
COOLANT VALVE 3
COOLANT WATER PUMP 1
COOLANT WATER PUMP 2
COOLANT WATER PUMP 3
ENGINE COOLING FAN MOTOR
ENGINE COOLING FAN RELAY
LEFT FRONT WINDSHIELD WIPER MOTOR
LEFT HEADLAMP ASSEMBLY
LOWER HIGH VOLTAGE BATTERY HORN PACK
LOWER HIGH VOLTAGE BATTERY PACK SHIELD
NCA WIRE
POWERTRAIN CONTROL MODULE
PTC HEATER
REMOTE FUNCTION ACTUATOR MODULE
RIGHT FRONT WINDSHIELD WIPER MOTOR
RIGHT HEADLAMP ASSEMBLY
TRANSMISSION CONTROL MODULE
UPPER HIGH VOLTAGE BATTERY PACK
UPPER HIGH VOLTAGE BATTERY PACK SHIELD
VACUUM PUMP MOTOR
VEHICLE AUDIO SIGNAL FOR PEDESTRIAN
VIO/GRY WIRE
WASHER FLUID LEVEL SWITCH
YEL WIRE
Go to component -> Ground distribution circuit, electric (1 of 3) -> VEHICLE AUDIO SIGNAL FOR PEDESTRIAN
vehicle audio signal for pedestrian wiring diagram (2 of 2)
AIR CONDITIONING CONTROL MODULE (ACCM)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF MOTOR COMPT)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH)
CONTACTOR RELAY
COOLANT WATER PUMP 1
COOLANT WATER PUMP 2
COOLANT WATER PUMP 3
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 6)
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 6)
FROM PCM POWER RELAY (DIAGRAM 1 OF 6)
FROM SPLICE
FUSE
FUSE 41
FUSE 42
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
IGNITION RELAY
IGNITION RELAY CONTROL
MICRO -
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
REAR JUNCTION BOX(RJB) (LEFT REAR CORNER OF VEHICLE)
REAR WINDOW WIPER MOTOR
REAR WIPER RELAY
RED WIRE
TO BODY CONTROL MODULE (BCM) (DIAGRAM 4 OF 6)
TO SPLICE
VEHICLE AUDIO SIGNAL FOR PEDESTRIAN
VIO/GRY WIRE
WHT WIRE
Go to component -> Power distribution circuit, electric (2 of 6) -> VEHICLE AUDIO SIGNAL FOR PEDESTRIAN
