Ford Focus III (2011-2015) sigrtn sigrtn e-sigrtn c-sigrtn sigrtn Wiring diagram
This page shows the only wiring diagram for the component.sigrtn sigrtn e-sigrtn c-sigrtn sigrtn, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sigrtn sigrtn e-sigrtn c-sigrtn sigrtn (1 of 1)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
DIGITAL
E-VREF LIN
ECT
ETCRTN FTP
FLP
FRP IAT
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/VIO WIRE
GRY/YEL WIRE
KNOCK
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR (INTAKE SYSTEM)
NCA WIRE
OIL PRESSURE SWITCH (LOWER LEFT OF REAR ENGINE)
OPS MAF
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE)
SIGRTN CKP SIGRTN E-SIGRTN
SIGRTN SIGRTN E-SIGRTN C-SIGRTN SIGRTN
STARTING/CHARGING SYSTEM
TACM+
UNIVERSAL HEATED OXYGEN
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VPREF
VREF E-VREF C-VREF VREF ETCREF
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l (6 of 6) -> SIGRTN SIGRTN E-SIGRTN C-SIGRTN SIGRTN
