Ford Focus III (2011-2015) return return drv l/r pass l/r pwr pass u/d driv u/d Wiring diagram
This page shows the only wiring diagram for the component.return return drv l/r pass l/r pwr pass u/d driv u/d, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram return return drv l/r pass l/r pwr pass u/d driv u/d (1 of 1)
BATTERY JUNCTION
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FUSE FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT W/ IGNITION RELAY ENERGIZED
LEFT FRONT RELAY
LOCK OUT SWITCH
MASTER WINDOW CONTROL SWITCH
MIRROR SWITCHES
MIRRORS SYSTEM
PWR
REAR SWITCH
RETURN RETURN DRV L/R PASS L/R PWR PASS U/D DRIV U/D
RIGHT FRONT SWITCH
RIGHT REAR SWITCH
VIO/BRN WIRE
VIO/GRN WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
