Ford Focus III (2011-2015) pwr pass l/r return pass u/d driv l/r return driv u/d Wiring diagram
This page shows the only wiring diagram for the component.pwr pass l/r return pass u/d driv l/r return driv u/d, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr pass l/r return pass u/d driv l/r return driv u/d (1 of 1)
4 1 7 UP DN
BATTERY
BLK WIRE
BLK/VIO WIRE
BRN/GRN WIRE
BRN/YEL WIRE
DN RIGHT FRONT SWITCH
DRIVER SIDE FRONT POWER WINDOW (BELOW FRONT DRIVER MOTOR SCUFF PLATE)
FUSE JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRY/ORG WIRE
HOT W/ IGNITION RELAY ENERGIZED
LEFT FRONT SWITCH
MASTER WINDOW CONTROL SWITCH
MIRROR SWITCHES PWR
MIRRORS SYSTEM
PASSENGER SIDE FRONT POWER WINDOW MOTOR
PASSENGER SIDE WINDOW CONTROL SWITCH
PWR PASS L/R RETURN PASS U/D DRIV L/R RETURN DRIV U/D
RIGHT FRONT SWITCH
VIO/GRN WIRE
WHT/VIO WIRE
Go to component -> Power windows circuit, except electric without door module & rear power window -> PWR PASS L/R RETURN PASS U/D DRIV L/R RETURN DRIV U/D
