Ford Focus III (2011-2015) master window control switch (w/o door modules) wiring diagram
This page shows the only wiring diagram for the component.master window control switch (w/o door modules), which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
master window control switch (w/o door modules) wiring diagram (1 of 1)
2.0L
2.0L TURBO
2.0L TURBO 2.0L
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) REAR WINDOW WIPER MOTOR
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BRN YEL/ WIRE
BRN/GRN WIRE
BRN/YEL (OR BLU) WIRE
BRN/YEL WIRE
COIL ON COIL ON PLUG PLUG (COP) 2 (COP) 4
COIL ON PLUG (COP) 2
COIL ON PLUG (COP) 3
COIL ON PLUG (COP) 4
CONTROL
EVAP CANISTER VENT VALVE
FLOOR SHIFTER (A/T)
FROM BATTERY JUNCTION (BJB) (DIAGRAM 2 OF 6)
FROM BATTERY JUNCTION 2.0L TURBO BOX (BJB) 2.0L (DIAGRAM FROM 1 OF 6) SPLICE
FROM FUSE 32 (DIAGRAM 1 OF 6)
FUSE
FUSE 35
FUSE 36
FUSE 39 FUSE 42
FUSE 41
FUSE FUSE FUSE
GRILLE SHUTTER ACTUATOR
GRN BRN/ WIRE
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ VIO WIRE
GRY/BRN WIRE
GRY/YEL WIRE
IGNITION
IGNITION RELAY
MASTER WINDOW CONTROL SWITCH (W/O DOOR MODULES)
NCA WIRE
PASSENGER SIDE WINDOW CONTROL SWITCH (W/O DOOR MODULES)
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE
POWERTRAIN CONTROL MODULE (PCM)
REAR WIPER RELAY
RED WIRE
RELAY
RIGHT HEADLAMP ASSEMBLY
TO (DIAGRAM SPLICE 1 OF 6)
TO BODY CONTROL MODULE (BCM) (DIAGRAM 3 OF 6)
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ HID
W/ REAR POWER WINDOWS W/O REAR POWER WINDOWS 2.0L TURBO
WHT/ VIO WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL BRN/ WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit, except electric (2 of 6) -> MASTER WINDOW CONTROL SWITCH (W/O DOOR MODULES)
