Ford Focus III (2011-2015) luggage compartment Wiring diagram
This page shows the only wiring diagram for the component.luggage compartment, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram luggage compartment (1 of 1)
4 DOOR
5 DOOR
ASSEMBLY (4 DOOR)
BLK WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CUPHOLDER LAMP
DRIVER DOOR RELEASE LAMP
DRIVER MAP POCKET LAMP
GRN/BLU WIRE
LAMP (4 DOOR)
LEFT FRONT FOOTWELL LAMP
LIFTGATE/ DECKLID LATCH
LUGGAGE COMPARTMENT
MASTER WINDOW CONTROL SWITCH
NCA WIRE
PASSENGER DOOR RELEASE LAMP
PASSENGER MAP POCKET LAMP
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT FRONT FOOTWELL LAMP
VPWR
W/O PASSENGER DOOR MODULE
WHT/BLU WIRE
YEL/ORG WIRE
Go to component -> Courtesy lamps circuit, except electric (3 of 3) -> LUGGAGE COMPARTMENT
