Ford Focus III (2011-2015) lin grille shutter actuator fcv Wiring diagram
This page shows the only wiring diagram for the component.lin grille shutter actuator fcv, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin grille shutter actuator fcv (1 of 1)
1 2 PWR GND
2.0L
2.0L (2.0L TURBO) (NEAR BREAKOUT TURBO
33 12 34 12 SIG RTN ECT
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONICS
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (RIGHT REAR OF ENGINE)
ENGINE COOLING FAN MOTOR (RADIATOR ASSEMBLY)
ENGINE COOLING FAN RELAY
FAN CONTROL VARIABLE
FUSE 32
FUSE 35
GRN WIRE
GRY WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN START OR RUN
HS CAN+
LIN
LIN GRILLE SHUTTER ACTUATOR FCV
MEGA FUSE 8
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE)
RED WIRE
STARTING/ CHARGING SYSTEM
VIO WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Cooling fan circuit, except electric -> LIN GRILLE SHUTTER ACTUATOR FCV
