Ford Focus III (2011-2015) liftgate/ rear decklid window latch wiper assembly motor Wiring diagram
This page shows the only wiring diagram for the component.liftgate/ rear decklid window latch wiper assembly motor, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate/ rear decklid window latch wiper assembly motor (1 of 1)
AUDIO CONTROL MODULE (ACM)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLOWER MOTOR LEFT FRONT SPEED FOOTWELL CONTROL LAMP
BRN/WHT WIRE
COMPASS MODULE
DATA LINK CONNECTOR (DLC)
FRONT CIGAR CUPHOLDER LIGHTER LAMP
FRONT RIGHT INTERIOR/ VANITY MAP LAMPS MIRROR ASSEMBLY LAMP
LEFT AUTO VANITY DIMMING MIRROR INTERIOR LAMP MIRROR
LIFTGATE/ DECKLID RELEASE SWITCH/ LAMP ASSEMBLY
LIFTGATE/ REAR DECKLID WINDOW LATCH WIPER ASSEMBLY MOTOR
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PARKING IMAGE AID PROCESSING MODULE MODULE B
PASSENGER DOOR MODULE (PDM)
PASSENGER DOOR RELEASE LAMP
PASSENGER POCKET MAP LAMP
PASSENGER SAFETY BELT BUCKLE SWITCH
PASSENGER SIDE FRONT HEATED SEAT MODULE
POWER STEERING CONTROL MODULE
PTC HEATER
REAR DOME LAMP
REAR HIGH WINDOW MOUNTED DEFROST STOP GRID LAMP
REAR POWER POINT
REMOTE OVERHEAD FUNCTIONS CONSOLE RECEIVER SWITCH (RFR) ASSEMBLY MODULE
RIGHT FRONT FOOTWELL LAMP
RIGHT FRONT SEAT BACKREST HEATER
RIGHT FRONT SEAT CUSHION HEATER
RIGHT REAR DOOR MODULE
RIGHT REAR LAMP ASSEMBLY
SENSOR
SMART DATA LINK CONNECTOR MODULE
VEDIO CAMERA SHIELD
W/ AMBIENT LIGHTING
W/ HEATED SEATS
W/ REAR VIEW CAMERA
WHT/VIO WIRE
YEL WIRE
Go to component -> Ground distribution circuit, electric (3 of 3) -> LIFTGATE/ REAR DECKLID WINDOW LATCH WIPER ASSEMBLY MOTOR
