Ford Focus III (2011-2015) image processing module b (right rear quarterpanel) wiring diagram
This page shows the only wiring diagram for the component.image processing module b (right rear quarterpanel), which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
image processing module b (right rear quarterpanel) wiring diagram (1 of 1)
1 2 3 4 5 6 GND MS CAN + MS CAN - VPWR
4 DOOR
5 DOOR
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXCEPT SYNC GEN 2
FUSE 29
GRN WIRE
GRY/ORG WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
IMAGE PROCESSING MODULE B (RIGHT REAR QUARTERPANEL)
LIN
NCA WIRE
PWR
REAR JUNCTION BOX (RJB) (LEFT REAR CORNER OF VEHICLE)
SHIELD
SYNC GEN 2
VIDEO CAMERA
VIDEO+
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Rear view camera circuit, except electric -> IMAGE PROCESSING MODULE B (RIGHT REAR QUARTERPANEL)
