Ford Focus III (2011-2015) hv lower positive Wiring diagram
This page shows the only wiring diagram for the component.hv lower positive, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hv lower positive (1 of 1)
1 2 3 4 HV BATT (-) HV BATT (+) HVIL IN HVIL OUT
AIR CONDITIONING CONTROL MODULE (ACCM)
BATTERY PACK (BEHIND REAR SEATS)
BATTERY PACK (UNDER REAR SEATS)
BLK WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DC TO DC CONVERTER CONTROL MODULE (DC/DC)
DC/DC HSD EN
EVHS CAN (-) DC/DC HSD EN
EVHS CAN -
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 6)
FRONT FUSE
GRN WIRE
GRN/YEL WIRE
HV BATT -
HV BATT- HV BATT+
HV LOWER POSITIVE
HV MAIN NEGATIVE
HV MAIN POSITIVE
HV UPPER NEGATIVE
HVIL SENSE
HVIL SOURCE
LOWER HIGH VOLTAGE
MIDDLE FUSE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/GRY WIRE
ORG/WHT WIRE
POWERTRAIN CONTROL MODULE (PCM)
PTC HEATER
REAR FUSE
TOP OF TRANSMISSION)
TRANSMISSION CONTROL MODULE (TCM)
UPPER HIGH VOLTAGE
VBATT
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
Go to component -> Power distribution circuit, electric (6 of 6) -> HV LOWER POSITIVE
