Ford Focus III (2011-2015) hs can - computer data lines system hs can + Wiring diagram

4 DOOR 5 DOOR ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT) BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/ORG WIRE BODY CONTROL MODULE (BCM) BRAKE FLUID LEVEL SWITCH (TOP OF MASTER BUCL SW - CASE GND COMPUTER DATA LINES SYSTEM CYLINDER RESERVOIR) DRIVER SAFETY BELT BUCKLE SWITCH DRIVER SEAT BUCKLE SW FUSE 78 FUSE 86 GRN WIRE GRN/VIO WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE HEADLAMP SWITCH HOT AT ALL TIMES HOT AT ALL TIMES HIGH CURRENT MEGA BATTERY FUSE JUNCTION BOX (BJB) HOT W/ IGN RELAY ENERGIZED HS CAN - COMPUTER DATA LINES SYSTEM HS CAN + HS CAN+ IGNITION SWITCH (W/O INTELLIGENT ACCESS) INSTRUMENT PANEL CLUSTER (IPC) INTERNAL ANTENNA RKE RECEIVER KEY IN IGNITION KEY-IN IGN LF DOOR AJAR LIFTGATE AJAR LIFTGATE/ DECKLID LATCH ASSEMBLY LIN LR DOOR AJAR LVL SW BRK FLUID MICRO - MS CAN + MS CAN + COMPUTER DATA LINES SYSTEM MS CAN - MULTI-FUNCTION LIN SWITCH NCA WIRE PARK BRAKE SW PARKING BRAKE SWITCH (CENTER CONSOLE) PASS SEAT BUCKLE SW PASSENGER SAFETY BELT BUCKLE SWITCH PWR GND RED WIRE RESTRAINTS CONTROL MODULE (CENTER CONSOLE) RF DOOR AJAR RR DOOR AJAR RTN RUN/START STEERING ANGLE SENSOR MODULE (SASM) (STEERING COLUMN ASSEMBLY) SUPPLEMENTAL RESTRAINTS SYSTEM VBATT VIO/ORG WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE YEL/ORG (OR BLK) WIRE YEL/ORG WIRE
