Ford Focus III (2011-2015) door lock/ hazard switch smart data link connector module Wiring diagram
This page shows the only wiring diagram for the component.door lock/ hazard switch smart data link connector module, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door lock/ hazard switch smart data link connector module (1 of 1)
BATTERY CHARGING CONTROL MODULE
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BREAKOUT TO CLOCKSPRING)
CHARGE PORT
CLOCK- SPRING
DATA LINK CONNECTOR (DLC)
DC/DC CONVERTER CONTROL MODULE
DOOR LOCK/ HAZARD SWITCH SMART DATA LINK CONNECTOR MODULE
DRIVE SIDE FRONT HEATED SEAT MODULE
DRIVER DOOR MODULE (DDM)
DRIVER DRIVER DOOR POCKET RELEASE MAP LAMP LAMP
FLOOR SHIFTER ILLUMINATION
FRONT CONTROLS INTERFACE HVAC MODULE CONTROL (FCIM) MODULE
GRN WIRE
GRN/YEL WIRE
HEADLAMP SWITCH
HORN SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT SEAT BACKREST HEATER
LEFT FRONT SEAT CUSHION HEATER
LEFT LEFT REAR POWER DOOR SEAT MODULE SWITCH
LEFT LOWER STEERING WHEEL SWITCH
LEFT REAR LAMP ASSEMBLY
LEFT UPPER STEERING WHEEL SWITCH
LOWER HIGH VOLTAGE BATTERY PACK
NCA WIRE
PARKING BRAKE SWITCH
PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR/ DEFROST SWITCH
PROX RESISTOR
REAR WIPER RELAY
RIGHT LOWER STEERING WHEEL SWITCH
RIGHT UPPER STEERING WHEEL SWITCH
STEERING ANGLE SENSOR FLOOR MODULE SHIFTER (SASM)
TELEMATIC CONTROL UNIT MODULE
UPPER HIGH VOLTAGE BATTERY PACK
W/ HEATED SEATS
YEL WIRE
YEL/GRY WIRE
Go to component -> Ground distribution circuit, electric (2 of 3) -> DOOR LOCK/ HAZARD SWITCH SMART DATA LINK CONNECTOR MODULE
