Ford Focus III (2011-2015) body control module (lower Wiring diagram
This page shows the only wiring diagram for the component.body control module (lower, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body control module (lower (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF MOTOR COMPT)
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (LOWER
BRN/GRN WIRE
COMPASS MODULE (CENTER OF ROOF)
COMPUTER DATA LINES SYSTEM
COURTESY
DIMMING RTN
DOME
FRONT INTERIOR/MAP LAMPS ASSEMBLY
FUSE
GRN WIRE
GRN/VIO WIRE
HIGH CURRENT
HOMELINK
HOT AT ALL TIMES
HS CAN+
INSTRUMENT ILLUMINATION CIRCUIT
INT LT RLY
INTERIOR LIGHT RELAY
LAMP CONTROL
LEFT LUGGAGE COMPARTMENT LAMP
LEFT VANITY MIRROR LAMP
LF DOOR AJAR
LIFTGATE AJAR
LIFTGATE/ DECKLID LATCH ASSEMBLY (BOTTOM CENTER OF LIFTGATE)
LIN 2
LR DOOR AJAR
MAP
MASTER WINDOW CONTROL SWITCH
MEGA FUSE 4
MEGA FUSE 9
MICRO -
MODULE
OFF
PWR GND
REAR DOME LAMP
RED WIRE
RF DOOR AJAR
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT VANITY MIRROR LAMP
RR DOOR AJAR
SWITCH ASSEMBLY
VBATT
VIO WIRE
VPWR
WHT WIRE
WHT/ BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Courtesy lamps circuit, electric (1 of 2) -> BODY CONTROL MODULE (LOWER
