Ford Focus III (2011-2015) 21 2 13 lin vbatt gnd window up window down illumination return Wiring diagram

1 4 3 VPWR GND LIN 21 2 13 LIN VBATT GND WINDOW UP WINDOW DOWN ILLUMINATION RETURN BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE DN UP FUSE GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE HALL SENSOR SUPPLY HOT AT ALL TIMES INTERIOR LIGHT RELAY LEFT REAR DOOR LATCH LEFT REAR DOOR MODULE LEFT REAR POWER WINDOW MOTOR LEFT REAR WINDOW CONTROL SWITCH MASTER WINDOW CONTROL SWITCH MICRO - RETURN RIGHT REAR DOOR LATCH RIGHT REAR POWER WINDOW MOTOR RIGHT REAR WINDOW CONTROL SWITCH TO LEFT REAR SPEAKER) VIO/ORG WIRE VIO/WHT WIRE WHT/BLU WIRE WINDOW DOWN WINDOW UP YEL WIRE YEL/GRY WIRE YEL/ORG WIRE
