Ford Focus III (2011-2015) 16 30 16 30 bps bpp Wiring diagram
This page shows the only wiring diagram for the component.16 30 16 30 bps bpp, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 16 30 16 30 bps bpp (1 of 1)
16 30 16 30 BPS BPP
2 1 MS CAN + MS CAN -
2.0L
2.0L TURBO
4 DOOR
5 DOOR
BACKUP LAMPS CIRCUIT
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BODY CONTROL MODULE
BODY CONTROL MODULE (BCM)
BRAKE PEDAL POSITION (BPP) SWITCH (BRAKE PEDAL SUPPORT BRACKET)
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CORNERING
DOOR LOCK/ HAZARD SWITCH (W/ SYNC GEN 2)
FUSE 21
FUSE 43
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/ORG WIRE
HAZARD
HEADLAMP CONTROL MODULE (HCM)
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
HS CAN+
INSTRUMENT CLUSTER
LEFT HEADLAMP ASSEMBLY
LEFT REAR LAMP ASSEMBLY
LIN 1
LT CORNERING
MICRO -
MS CAN +
MULTIFUNCTION SWITCH
PARK
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE)
REVERSE
RIGHT HEADLAMP ASSEMBLY
RIGHT REAR LAMP ASSEMBLY
RT CORNERING
STEERING ANGLE SENSOR MODULE (SASM) (STEERING COLUMN ASSEMBLY)
STOP
STOP LGT SW
TURN
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
W/O DOOR MODULE
WARNING SW SIG
WHT WIRE
WHT/BLU WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit, except electric (1 of 2) -> 16 30 16 30 BPS BPP
