Ford Focus III (2011-2015) 14 1 5 4 7 8 pwr gnd vbatt hs can - hs can + Wiring diagram
This page shows the only wiring diagram for the component.14 1 5 4 7 8 pwr gnd vbatt hs can - hs can +, which is found in the car Ford Focus III (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 14 1 5 4 7 8 pwr gnd vbatt hs can - hs can + (1 of 1)
12 13 MS CAN + MS CAN -
14 1 5 4 7 8 PWR GND VBATT HS CAN - HS CAN +
17 4 DISP SIGNAL DISP TRIP GND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH)
BRN/RED WIRE
CLOCKSPRING (TOP OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
DOWN
FRONT CONTROLS INTERFACE MODULE
FUSE 79
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE 72
I CAN + VBATT
I CAN - GND
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL SPEAKER
LEFT
LEFT UPPER STEERING WHEEL SWITCH
LT BLU WIRE
MICRO -
NCA WIRE
ORG/ WIRE
RIGHT
RIGHT UPPER STEERING WHEEL SWITCH
SASM SUPPLY
STEERING ANGLE SENSOR MODULE
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
Go to component -> Radio circuit, electric (2 of 2) -> 14 1 5 4 7 8 PWR GND VBATT HS CAN - HS CAN +
