Ford Focus III (2011-2015) 13 12 ms can- ms can+ Wiring diagrams
This page contains all the electrical diagrams for the component. 13 12 ms can- ms can+, in which he is found in the car Ford Focus III (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 13 12 ms can- ms can+ (1 of 2)
13 12 MS CAN- MS CAN+
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (LEFT REAR CORNER OF MOTOR COMPT)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF MOTOR COMPT)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BST PWR VAC PUMP MP SIG VPWR VAC SEN SIG
COMPUTER DATA LINES SYSTEM
EVHS CAN+ EVHS CAN- VAC SENS PWR VAC SEN GND
FUSE 19 FUSE FUSE
GRN/BRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGN RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LEFT REAR WHEEL SPEED SENSOR (LEFT REAR HUB ASSEMBLY)
MP GND BST PWM VBATT
MP SENSE PAS GND
NCA WIRE
PAS SIG 1 VAC PUMP MON PAS SIG 2 PAS SENSE
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT HUB ASSEMBLY)
VACRC
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Anti-lock brakes circuit, electric (1 of 2) -> 13 12 MS CAN- MS CAN+
Wiring diagram 13 12 ms can- ms can+ (2 of 2)
1 2 3 4 5 6 RUN/START HS CAN + HS CAN - GND BTS_VREF BTF_SIG
13 12 MS CAN- MS CAN+
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SAFETY BELT ANCHOR PRETENSIONER (BASE OF DRIVER "B" PILLAR)
ENS
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT IMPACT SEVERITY SENSOR (LEFT FRONT CORNER OF MOTOR COMPT)
LEFT SIDE AIR CURTAIN MODULE (TOP OF LEFT "C" PILLAR)
NCA WIRE
PASSENGER AIR BAG MODULE
PASSENGER SAFETY BELT ANCHOR PRETENSIONER (BASE OF PASSENGER "B" PILLAR)
PASSENGER SAFETY BELT BUCKLE
PASSENGER SAFETY BELT LOAD LIMITING RETRACTOR (BASE OF RIGHT "B" PILLAR)
PASSENGER SAFETY BELT RETRACTOR PRETENSIONER (BASE OF RIGHT "B" PILLAR)
RIGHT FRONT IMPACT SEVERITY SENSOR (RIGHT FRONT CORNER OF MOTOR COMPT)
RIGHT FRONT SIDE AIR BAG MODULE
RIGHT SIDE AIR CURTAIN MODULE (TOP OF RIGHT "C" PILLAR)
SHORTING BAR
STAGE 1
STAGE 2
UPPER HIGH VOLTAGE BATTERY PACK (BEHIND REAR SEATS)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit, electric (2 of 2) -> 13 12 MS CAN- MS CAN+
