Ford Focus III (2011-2015) 1 2 3 4 sig sw lck sw ind illum Wiring diagrams
This page contains all the electrical diagrams for the component. 1 2 3 4 sig sw lck sw ind illum, in which he is found in the car Ford Focus III (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 1 2 3 4 sig sw lck sw ind illum (1 of 2)
1 2 3 4 SIG SW LCK SW IND ILLUM
1 5 4 14 VBATT HS CAN - HS CAN + PWR GND
21 4 3 SHIELD SYNC ALERT- SYNC ALERT+
4 5 I CAN - I CAN +
5 6 8 7 GND LCK SW IND VBATT LIN
6 5 4 3 2 1 GND
8 4 5 LIN I CAN + I CAN -
ACCESSORY PROTOCOL INTERFACE MODULE (CENTER OF DASH)
ALERT -
AUDIO REMOTE-
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CPLXX
DISPLAY SIG +
DISPLAY/ TRIP GND
DOOR LOCKS SYSTEM
DOWN
ENABLE
EXTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM
FRONT CONTROL/DISPLAY INTERFACE MODULE(FCDIM)
FUSE 67
FUSE 72
FUSE 79
GLOBAL POSITIONING SYSTEM MODULE
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT UPPER STEERING WHEEL SWITCH
LT BLU WIRE
MEDIA HUB
MS CAN - MS CAN + VBATT
NCA WIRE
ORG/ WIRE
PWR GND
RIGHT LOWER STEERING WHEEL SWITCH
RIGHT UPPER STEERING WHEEL SWITCH
SDL -
SEEK- MODE
STEERING ANGLE SENSOR MODULE
STEERING COLUMN ASSEMBLY
STEREO L+
STEREO R+
SYNC RADIO CIRCUIT
USB
USB VBATT HS CAN + HS CAN - 1 53 54
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE/ START 1 START 2 MUTE
VOL - VOL + SEEK +
W/ SYNC GEN 1
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, except electric with sony (2 of 2) -> 1 2 3 4 SIG SW LCK SW IND ILLUM
Wiring diagram 1 2 3 4 sig sw lck sw ind illum (2 of 2)
1 2 3 4 SIG SW LCK SW IND ILLUM
1 5 4 14 VBATT HS CAN - HS CAN + PWR GND
21 4 3 SHIELD SYNC ALERT- SYNC ALERT+
4 5 I CAN - I CAN +
5 6 8 7 GND LCK SW IND VBATT LIN
6 5 4 3 2 1 GND
8 4 5 LIN I CAN + I CAN -
ACCESSORY PROTOCOL INTERFACE MODULE (CENTER OF DASH)
ALERT -
AUDIO REMOTE-
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CPLXX
DISPLAY SIG +
DISPLAY/ TRIP GND
DOOR LOCKS SYSTEM
DOWN
ENABLE
EXTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM
FRONT CONTROL/DISPLAY INTERFACE MODULE(FCDIM)
FUSE 67
FUSE 72
FUSE 79
GLOBAL POSITIONING SYSTEM MODULE
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT UPPER STEERING WHEEL SWITCH
LT BLU WIRE
MEDIA HUB
MS CAN - MS CAN + VBATT
NCA WIRE
ORG/ WIRE
PWR GND
RIGHT LOWER STEERING WHEEL SWITCH
RIGHT UPPER STEERING WHEEL SWITCH
SDL -
SEEK- MODE
STEERING ANGLE SENSOR MODULE
STEERING COLUMN ASSEMBLY
STEREO L+
STEREO R+
SYNC RADIO CIRCUIT
USB
USB VBATT HS CAN + HS CAN - 1 53 54
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE/ START 1 START 2 MUTE
VOL - VOL + SEEK +
W/ SYNC GEN 1
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Sony radio circuit, except electric (2 of 2) -> 1 2 3 4 SIG SW LCK SW IND ILLUM
