Wiper/washer circuit for Ford Focus II facelift (2007-2011)

Wiper/washer circuit

Get access

6. INT 5 7. LOW 8. HIGH BLK WIRE BLU WIRE BRN WIRE ELECTRONICS FRONT WASH FRONT WASHER RELAY FRONT WIPER FUSE GRN WIRE GRY WIRE HALL SENSOR HIGH/ LOW SPEED RELAY HOT IN RUN OR ACC LOGIC WIPER MOTOR ON INPUT MULTIFUNCTION SWITCH ORG/ WIRE RED WIRE RUN/ PARK RELAY SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE WINDSHIELD WASHER PUMP MOTOR (WASHER FLUID RESERVOIR) WIPER POWER RELAY YEL WIRE
