Charging circuit for Ford Focus II facelift (2007-2011)

Charging circuit

Get access

BATTERY BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT) BLK WIRE BLU/ORG WIRE BRN WIRE CAN (+) COMPUTER DATA LINES SYSTEM FUSE 6 GENCOM GENERATOR RC GENMON INSTRUMENT CLUSTER (IC) LEFT FRONT STRUT TOWER) POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE) RED WIRE STARTING CIRCUIT VIO WIRE WHT WIRE WHT/BLU WIRE
