Base radio circuit for Ford Focus II facelift (2007-2011)
Base radio circuit
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 B +
ANTENNA
AUDIO CONTROL MODULE (ACM)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FRONT LEFT+ REAR LEFT+ REAR RIGHT+ FRONT RIGHT+ FRONT RIGHT- GND
FRONT LEFT- REAR LEFT- REAR RIGHT-
FUSE 28
FUSE 39
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN
LEFT LEFT REAR FRONT SPEAKER SPEAKER
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
SMART JUNCTION BOX (SJB)
ST SIG
VPWR
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
