Power seats circuit for Ford Focus II facelift (2007-2011)
Power seats circuit
1 5 DRV HTD SEAT RLY PASS HTD SEAT RLY
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
DRIVER HEATED SEAT RELAY (UNDER DRIVER'S SEAT)
DRIVER SIDE SEAT CUSHION/BACKREST HEATER MAT
DRIVER'S SEAT
FUSE 18
FUSE 43
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
HVAC MODULE (CENTER OF DASH)
PASSENGER HEATED SEAT RELAY (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SIDE SEAT CUSHION/BACKREST HEATER MAT
RED WIRE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
