Power door locks circuit for Ford Focus II facelift (2007-2011)
Power door locks circuit (1 of 2)
ALL LOCK RELAY
ALL UNLOCK RELAY
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/YEL WIRE
DECKLID RELEASE RELAY
DECKLID RLY
DF DR AJAR
DOOR AJAR
DR LOCK DR UNLOCK PR DR AJAR DR DR AJAR
DRIVER SIDE FRONT DOOR LOCK UNIT (DRIVER'S DOOR)
DRIVER UNLOCK RELAY
FUSE 17
FUSE 24
FUSE 41
GRN WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HORN RELAY
HORN RLY AJAR SW
HORNS SYSTEM
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
LEFT REAR DOOR LOCK ACTUATOR (SEDAN)
LOGIC
PF DR AJAR
PR DR AJAR
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TPMS/RKE RECEIVER INTERNAL ANTENNA
VIO/ BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Power door locks circuit (2 of 2)
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BRN/YEL WIRE
DOOR AJAR
DRIVER SIDE DOOR LOCK SWITCH
GRY/BRN WIRE
GRY/ORG WIRE
LUGGAGE COMPARTMENT LID RELEASE SOLENOID (IN DECKLID)
PASSENGER SIDE DOOR LOCK SWITCH UNLOCK LOCK
PASSENGER SIDE FRONT DOOR LOCK UNIT
RIGHT REAR DOOR LOCK ACTUATOR (SEDAN) (RIGHT REAR DOOR)
UNLOCK LOCK
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/VIO WIRE
