Instrument cluster circuit for Ford Focus II facelift (2007-2011)

17 18 25 26 HS CAN+ HS CAN- DRV BUCKLE PASS BUCKLE AJAR DF DOOR AJAR DR DOOR AJAR PR DOOR BACK LIGHTING LED (FET) BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/RED WIRE BRAKE FLUID LEVEL SWITCH (TOP OF MASTER CYLINDER RESERVOIR) BRK FLUID SW COMPASS COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ANTI-THEFT SYSTEM DRIVER SAFETY BELT BUCKLE PRETENSIONER (UNDER DRIVER'S SEAT) DRIVER SIDE FRONT DOOR LOCK UNIT DRIVER'S DOOR ELECTROCHROMATIC INSIDE MIRROR UNIT FUEL PUMP MODULE (FUEL TANK ASSEMBLY) FUSE 10 FUSE 26 FUSE 27 FUSE 29 GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN START OR RUN HS CAN- HS CAN+ COMPASS + COMPASS - IGNITION SWITCH INSTRUMENT CLUSTER (IC) KEY-IN IGN LEFT REAR DOOR LOCK ACTUATOR (SEDAN) LOGIC MESSAGE CENTER SWITCH MS CAN + MSG CENTER RTN FUEL SENDER RTN MSG CENTER SW FUEL SENDER IN OIL PRESS SW GND OIL PRESSURE SWITCH (LOWER LEFT OF ENGINE) PAD INDICATOR/ TRACTION CONTROL/ AMBIENT LIGHTING SWITCH PARK BRK PARKING BRAKE SWITCH (CENTER CONSOLE) PASSENGER SAFETY BELT BUCKLE PRETENSIONER PASSENGER SIDE FRONT DOOR LOCK UNIT PF DOOR AJAR RESTRAINTS CONTROL MODULE (RCM) (CENTER CONSOLE) RIGHT REAR DOOR LOCK ACTUATOR (SEDAN) (RIGHT REAR DOOR) SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) TCS ON/OFF VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
