Passive anti-theft circuit for Ford Focus II facelift (2007-2011)
Passive anti-theft circuit
1 2 3 4 RF POWER RF GROUND TX SIGNAL RX SIGNAL
43 59 CAN - CAN +
BLK/VIO WIRE
BLU/BRN WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
FUSE
HOT IN START OR RUN
INSTRUMENT CLUSTER (IC)
PASSIVE ANTI-THEFT TRANSCEIVER MODULE (STEERING COLUMN ASSEMBLY)
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE)
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
YEL/ORG WIRE
