Ford Focus II facelift (2007-2011) passenger side seat cushion/backrest heater mat wiring diagram
This page shows the only wiring diagram for the component.passenger side seat cushion/backrest heater mat, which is found in the car Ford Focus II facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passenger side seat cushion/backrest heater mat wiring diagram (1 of 1)
1 5 DRV HTD SEAT RLY PASS HTD SEAT RLY
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
DRIVER HEATED SEAT RELAY (UNDER DRIVER'S SEAT)
DRIVER SIDE SEAT CUSHION/BACKREST HEATER MAT
DRIVER'S SEAT
FUSE 18
FUSE 43
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
HVAC MODULE (CENTER OF DASH)
PASSENGER HEATED SEAT RELAY (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SIDE SEAT CUSHION/BACKREST HEATER MAT
RED WIRE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Power seats circuit -> PASSENGER SIDE SEAT CUSHION/BACKREST HEATER MAT
