Ford Focus II facelift (2007-2011) oss cpp bt cpp tt Wiring diagram
This page shows the only wiring diagram for the component.oss cpp bt cpp tt, which is found in the car Ford Focus II facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oss cpp bt cpp tt (1 of 1)
13 46 59 43 50 BPP BPS CAN + CAN - GND
ANTI-LOCK BRAKES SYSTEM
AUTOMATIC TRANSMISSION
BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT)
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL SUPPORT BRACKET)
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUTCH PEDAL SPEED CONTROL DEACTIVATOR SWITCH (M/T) (CLUTCH PEDAL SUPPORT)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
FLOOR SHIFTER (CENTER CONSOLE)
FUSE 26
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/VIO WIRE
HARNESS, NEAR BREAKOUT TO HEATED OXYGEN
HOT AT ALL TIMES SMART JUNCTION FUSE 2 BOX (SJB) (BEHIND LEFT SIDE OF DASH)
HOT W/ PCM POWER RELAY ENERGIZED
O/D SWITCH
OSS CPP BT CPP TT
OUTPUT SHAFT SPEED (OSS) SENSOR (A/T) (REAR OF TRANSMISSION)
OUTPUT SHAFT SPEED (OSS) SENSOR (M/T) (REAR OF TRANSMISSION)
PCA
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE)
STARTING/ CHARGING SYSTEM
TFT 5 4 2 7
TRANSMISSION HARDWARE UNIT (LEFT REAR OF TRANSMISSION)
TRANSMISSION RANGE (TR) SENSOR (LEFT SIDE OF TRANSMISSION)
TURBINE SHAFT SPEED (TSS) SENSOR (TOP OF TRANSMISSION)
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
WIRING HARNESS, NEAR BREAKOUT TO POWERTRAIN CONTROL MODULE)
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Transmission circuit -> OSS CPP BT CPP TT
