Ford Focus II facelift (2007-2011) key in ignition Wiring diagram
This page shows the only wiring diagram for the component.key in ignition, which is found in the car Ford Focus II facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key in ignition (1 of 1)
43 59 CAN - CAN +
BATTERY JUNCTION
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL SUPPORT BRACKET)
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BSI (FET)
COMPUTER DATA LINES SYSTEM
CONSOLE)
FLOOR SHIFTER (CENTER
FUSE 2
FUSE 26 BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT)
FUSE 27
FUSE 5
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
IGN SW
IGNITION SWITCH
ILLUM
JUNCTION WIRING HARNESS, NEAR BREAKOUT TO BRAKE FLUID LEVEL
KEY IN IGNITION
LOCK
LOGIC BRAKE PEDAL SW
LOW DRIVE NEUTRAL REVERSE PARK TCS 20 41 35 8 30
MS MS CAN CAN
O/D SWITCH
ORG/ WIRE
PARK RANGE
POWERTRAIN CONTROL MODULE
RED WIRE
SHIFT LOCK
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
SWITCH
TRANSMISSION RANGE SENSOR (LEFT SIDE OF TRANSMISSION)
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Shift interlock circuit -> KEY IN IGNITION
