Ford Focus II facelift (2007-2011) gnd common delacc tilt open b+ Wiring diagram
This page shows the only wiring diagram for the component.gnd common delacc tilt open b+, which is found in the car Ford Focus II facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd common delacc tilt open b+ (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/YEL WIRE
CIRCUIT BREAKER 47
CLOSE
COMMON
FUSE 19
FUSE 41
GND COMMON DELACC TILT OPEN B+
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
ORG/ WIRE
RED WIRE
ROOF OPENING PANEL CONTROL SWITCH 0) RESET 1) OPEN 2) CLOSE
ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF)
SLIDE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TILT
VIO WIRE
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit -> GND COMMON DELACC TILT OPEN B+
