Ford Focus II facelift (2007-2011) front passenger side door lock unit Wiring diagram
This page shows the only wiring diagram for the component.front passenger side door lock unit, which is found in the car Ford Focus II facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger side door lock unit (1 of 1)
BLK WIRE
BLU WIRE
CLOCK- SPRING
CLUTCH CUTOFF SWITCH
CLUTCH PEDAL SPEED CONTROL DEACTIVATION SWITCH
DATA LINK CONNECTOR
DRIVER SAFETY BELT BUCKLE PRETENSIONER
DRIVER SEAT POSITION SENSOR
ELECTRO- CHROMATIC INSIDE MIRROR UNIT
FRONT CONTROL INTERFACE MODULE (FCIM)
FRONT DISPLAY INTERFACE MODULE (FDIM)
FRONT PASSENGER SIDE DOOR LOCK UNIT
FUEL TANK UNIT
GRN WIRE
GRY WIRE
INSTRUMENT CLUSTER (IC)
LUGGAGE COMPARTMENT LID RELEASE SWITCH
MAIN LIGHT SWITCH
MESSAGE CENTER SWITCH
MULTIFUNCTION SWITCH
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PAD INDICATOR/ TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
PARK BRAKE SWITCH
PASSENGER SAFETY BELT BUCKLE PRETENSIONER
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
PASSENGER SIDE SEAT CUSHION/ BACKREST HEATER MAT
PASSIVE ANTI-THEFT TRANSCEIVER MODULE
RIGHT REAR DOOR LOCK ACTUATOR
SUBWOOFER AMPLIFIER
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 3) -> FRONT PASSENGER SIDE DOOR LOCK UNIT
