Ford Focus II facelift (2007-2011) cruise control system supplemental restraints system Wiring diagram
This page shows the only wiring diagram for the component.cruise control system supplemental restraints system, which is found in the car Ford Focus II facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control system supplemental restraints system (1 of 1)
ACC/ DELAY RELAY
ALL LOCK RELAY PWR GND LOGIC GND
BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CRUISE CONTROL SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
DECKLID RELEASE RELAY
DF DOOR AJAR PR DOOR AJAR LIFTGATE/DECKLID GLASS AJAR SW DOOR LOCK
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM POWER DISTRIBUTION SYSTEM
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM
LOGIC GND
MIRRORS SYSTEM
ONE TOUCH INTEGRATED START DIODE
PARK LP RELAY BATT SAVER RELAY
POWER DISTRIBUTION SYSTEM
PWR GND LR STOP/TURN LP RR STOP/TURN LP UNLOCK/LOCK RELAY DRV UNLOCK RELAY
SHIFT INTERLOCK SYSTEM
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
SOUND SYSTEMS
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Body control modules circuit (2 of 2) -> CRUISE CONTROL SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
