Ford Focus II facelift (2007-2011) all unlock relay Wiring diagrams
This page contains all the electrical diagrams for the component. all unlock relay, in which he is found in the car Ford Focus II facelift (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram all unlock relay (1 of 2)
ALL LOCK RELAY
ALL UNLOCK RELAY
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/YEL WIRE
DECKLID RELEASE RELAY
DECKLID RLY
DF DR AJAR
DOOR AJAR
DR LOCK DR UNLOCK PR DR AJAR DR DR AJAR
DRIVER SIDE FRONT DOOR LOCK UNIT (DRIVER'S DOOR)
DRIVER UNLOCK RELAY
FUSE 17
FUSE 24
FUSE 41
GRN WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HORN RELAY
HORN RLY AJAR SW
HORNS SYSTEM
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
LEFT REAR DOOR LOCK ACTUATOR (SEDAN)
LOGIC
PF DR AJAR
PR DR AJAR
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TPMS/RKE RECEIVER INTERNAL ANTENNA
VIO/ BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Forced entry circuit (1 of 2) -> ALL UNLOCK RELAY
