Ford Focus II facelift (2007-2011) 13 46 59 43 50 bpp bps can + can - gnd Wiring diagram

13 46 59 43 50 BPP BPS CAN + CAN - GND ANTI-LOCK BRAKES SYSTEM AUTOMATIC TRANSMISSION BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT) BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL SUPPORT BRACKET) BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CLUTCH PEDAL SPEED CONTROL DEACTIVATOR SWITCH (M/T) (CLUTCH PEDAL SUPPORT) COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM FLOOR SHIFTER (CENTER CONSOLE) FUSE 26 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/BLU WIRE GRY/VIO WIRE HARNESS, NEAR BREAKOUT TO HEATED OXYGEN HOT AT ALL TIMES SMART JUNCTION FUSE 2 BOX (SJB) (BEHIND LEFT SIDE OF DASH) HOT W/ PCM POWER RELAY ENERGIZED O/D SWITCH OSS CPP BT CPP TT OUTPUT SHAFT SPEED (OSS) SENSOR (A/T) (REAR OF TRANSMISSION) OUTPUT SHAFT SPEED (OSS) SENSOR (M/T) (REAR OF TRANSMISSION) PCA POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE) STARTING/ CHARGING SYSTEM TFT 5 4 2 7 TRANSMISSION HARDWARE UNIT (LEFT REAR OF TRANSMISSION) TRANSMISSION RANGE (TR) SENSOR (LEFT SIDE OF TRANSMISSION) TURBINE SHAFT SPEED (TSS) SENSOR (TOP OF TRANSMISSION) VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE WIRING HARNESS, NEAR BREAKOUT TO POWERTRAIN CONTROL MODULE) YEL/GRY WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
