Ford Focus II facelift (2007-2011) 13 43 59 bpp hs can - hs can + Wiring diagrams
This page contains all the electrical diagrams for the component. 13 43 59 bpp hs can - hs can +, in which he is found in the car Ford Focus II facelift (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 13 43 59 bpp hs can - hs can + (1 of 2)
13 43 59 BPP HS CAN - HS CAN +
2 1 15 14 22 MS CAN+ MS CAN- HS CAN+ HS CAN- TCS ON/OFF
BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRAKE PEDAL MS SW CAN+
BRN WIRE
BRN/GRN WIRE
CLUS GND
CLUS PWR
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 2
FUSE 31
GRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
HS CAN + HS CAN -
HS CAN YAW - HS CAN YAW +
IGN SAS B
INSTRUMENT CLUSTER (IC)
IVD RTN SAS A RR WHL SPD- RR WHL SPD+
IVD SIG BPP
LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT WHEEL HUB)
LF WHL SPD+ LF WHL SPD-
LR WHL SPD LR WHL SPD
MS CAN +
NCA WIRE
ORG/ WIRE
PAD INDICATOR/ TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
POSITION SWITCH)
POWERTRAIN CONTROL MODULE
RED WIRE
RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR WHEEL HUB)
SMART JUNCTION LOGIC BOX (SJB) (BEHIND LEFT SIDE OF DASH) BRAKE FLUID SW
SOLID STATE
STABILITY CONTROL SENSOR CLUSTER
STEERING ANGLE SENSOR MODULE (LEFT SIDE OF DASH)
TRACTION ON/OFF SWITCH
VBATT RF WHL SPD- RF WHL SPD+
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit, with dynamic stability control -> 13 43 59 BPP HS CAN - HS CAN +
Wiring diagram 13 43 59 bpp hs can - hs can + (2 of 2)
13 43 59 BPP HS CAN - HS CAN +
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (LEFT REAR CORNER OF ENGINE COMPT)
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BPP
BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL
BREAKOUT TO LEFT REAR OF ENGINE COMPT)
BRK PEDAL SW
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FLASH TO PASS
FLASH TO PASS SWITCH
FUSE 2
FUSE 22
GRN/BRN WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HAZARD
HAZARD SWITCH
HI BEAM
HIGH MOUNTED STOPLAMP
HOT AT ALL TIMES
HOT AT ALL TIMES SMART JUNCTION BOX (SJB) FUSE 6 (BEHIND LEFT SIDE OF DASH)
INSTRUMENT CLUSTER (IC)
LAMP
LEFT FRONT PARK/ TURN LAMP
LEFT FRONT SIDE LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/ STOP/TURN LAMP
LEFT TURN
LF TURN LAMP (FET) LR STOP/ TURN LAMP (FET)
LO BEAM PARK
LOGIC
MAIN LIGHT SWITCH
MS CAN +
MULTI-FUNCTION SWITCH (STEERING COLUMN)
OFF
PARK
PARK LAMP ON
PARK LAMP RELAY
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE)
RF TURN LAMP (FET)
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE LAMP
RIGHT LICENSE PLATE
RIGHT REAR PARK/ STOP/TURN LAMP
RIGHT TURN
RR STOP/ TURN LAMP (FET)
STOP TURN
SUPPORT BRACKET)
TURN
TURN SIGNAL SWITCH
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit -> 13 43 59 BPP HS CAN - HS CAN +
