Intermittent wiper/washer circuit for Ford Focus II (2005-2008)
Intermittent wiper/washer circuit
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FUSE 56
GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR)
GRN/ORG WIRE
GRN/RED WIRE
HOT IN START OR RUN
LOW HIGH
OFF
OFF INT
OFF WASHER ON
PARK
RUN WIRE
SINGLE
TWO-WAY WASHER PUMP MOTOR (ON BOTTOM OF WASHER FLUID RESERVOIR)
VARIABLE INTERMITTENT WIPE
W/ REAR WIPER
W/O REAR WIPER
WASHER ON
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WINDSHIELD WIPER MOTOR (ON TOP CENTER OF FIREWALL)
WINDSHIELD WIPER RELAY
WIPER ON
WIPER/WASHER SWITCH
YEL/BLK WIRE
