Shift interlock circuit for Ford Focus II (2005-2008)
Shift interlock circuit
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FUSE 42
FUSE 8
GEARSHIFT O/D SWITCH LEVER UNIT (IN CENTER CONSOLE)
GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
IGNITION SWITCH
ILLUMINATION
KEY REMOVAL INHIBIT SOLENOID
ORG/ WIRE
PARK INTERLOCK SOLENOID
RED WIRE
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT)
TRANSMISSIONS SYSTEM
WHT WIRE
YEL WIRE
