Power windows circuit, with rear power windows for Ford Focus II (2005-2008)
Power windows circuit, with rear power windows
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DN REST REST ONE- TOUCH DOWN ONE- TOUCH DOWN
DRIVER SWITCH
FUSE 54
FUSE 55
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT IN START OR RUN
ILLUMINATION
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR SWITCH
LEFT REAR WINDOW ADJUST SWITCH
LOCK
MASTER WINDOW ADJUST SWITCH
ONE-TOUCH WINDOW RELAY (IN DRIVER DOOR, BEHIND TRIM PANEL)
ORG/ WIRE
PASS SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
RED WIRE
REST UP
RIGHT REAR SWITCH
RIGHT REAR WINDOW ADJUST SWITCH
TO PASSENGER SIDE WINDOW ADJUST SWITCH (DIAGRAM 1 OF 1)
UP DN
VIO WIRE
WHT WIRE
YEL WIRE
