Power top/sunroof circuit for Ford Focus II (2005-2008)
Power top/sunroof circuit
1 2 3 4 5 6 7 8 9 10 VBATT
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DOWN/ OPEN
FUSE 34
FUSE 43
GRN/BLK WIRE
GRN/BLU WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
MOONROOF ADJUST SWITCH
ORG/BLK WIRE
ROOF OPENING PANEL UNIT (AT CENTER FRONT OF ROOF)
UP/ CLOSE
VSS
VSS VPWR VREF VREF GND
WHT/BLU WIRE
WHT/VIO WIRE
