Cruise control circuit, a/t for Ford Focus II (2005-2008)
Cruise control circuit, a/t
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
BRN WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
CLOCK SPRING (ON STEERING COLUMN)
COAST/RESUME
COMPARTMENT)
DECEL
FUSE 29
FUSE 42
FUSE 53
FUSE 61
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT IN START OR RUN
INSTRUMENT CLUSTER
MICRO- PROCESSOR
NCA WIRE
OFF
OUTPUT SHAFT SPEED (OSS) SENSOR (ON REAR OF TRANSMISSION)
RED WIRE
REST
SET/ACC
SPEED CONTROL INDICATOR
SPEED CONTROL SERVO (LEFT SIDE OF ENGINE
STEERING WHEEL/ SPEED CONTROL SWITCH
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
