Body control modules circuit for Ford Focus II (2005-2008)

Body control modules circuit (1 of 2)

Focus Ford II (2005-2008): Body control modules circuit (1 of 2)

Get access

ANTI-THEFT INHIBIT SW IN LR DOOR AJAR SW IN LOCK SW CIRCUIT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DOOR LOCK SW RESET SIG LOCK SIG DOOR LOCK SW SET SIG DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM ENGINE COMPT SW IN EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM FUSE 32 FUSE 63 GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR) GROUND HOT AT ALL TIMES INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM LATE PRODUCTION ORG/GRN WIRE ORG/WHT WIRE PULSED POWER FEED SWITCHED GROUND RR DOOR AJAR SW IN UNLOCK SW CIRCUIT UNLOCK SIG LIFTGATE AJAR SW IN WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WIPER/WASHER SYSTEM YEL/BLK WIRE

Body control modules circuit (2 of 2)

Focus Ford II (2005-2008): Body control modules circuit (2 of 2)

Get access

BATTERY SAVER RELAY BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DOOR LOCKS SYSTEM GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR) GRN/WHT WIRE GRN/YEL WIRE HORN RLY CTRL REAR WIN DEFROST RLY CTRL RELEASE SW IN REAR WIPER RLY CTRL HORNS SYSTEM DEFOGGER SYSTEM DOOR LOCKS SYSTEM WIPER/WASHER SYSTEM INSTRUMENT CLUSTER SYSTEM KEY WARNING SW IN STOP LAMP SW SIG LIFTGATE ANTI-THEFT INHIBIT SW ORG/WHT WIRE ORG/YEL WIRE RED/BLK WIRE WARNING SYSTEM EXTERIOR LIGHTS SYSTEM WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM EXTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM YEL/BLK WIRE
