Forced entry circuit for Ford Focus II (2005-2008)

Forced entry circuit (1 of 2)

Get access

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH, ON CENTRAL JUNCTION BOX) DRIVER SIDE DOOR LOCK SWITCH ENGINE COMPARTMENT SWITCH (IN FRONT CENTER OF ENGINE COMPT) EXTERIOR LIFTGATE/ DECKLID RELEASE SWITCH FUSE 32 FUSE 63 GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR) GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HORNS SYSTEM HOT AT ALL TIMES ILLUMINATION INSTRUMENT CLUSTER STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT) LIFTGATE/ DECKLID RELEASE SWITCH LOCK ORG/GRN WIRE ORG/WHT WIRE PASSENGER SIDE DOOR LOCK SWITCH UNLOCK WAGON WHT/BLK WIRE WHT/GRN WIRE YEL/BLK WIRE

Get access

3-DOOR 5-DOOR ANTI-THEFT INNIBIT SWITCH BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE CENTRAL CENTRAL LOCK DRIVER SIDE FRONT DOOR AJAR SWITCH (ON LEFT "B" PILLAR) DRIVER SIDE FRONT DOOR LOCK UNIT (IN DRIVER'S DOOR) DRIVER SIDE REAR DOOR AJAR SWITCH (ON LEFT "C" PILLAR) INTERIOR LIGHTS SYSTEM HARNESS, IN BREAKOUT TO LIFTGATE/LATCH ASSEMBLY) LATE PRODUCTION EARLY PRODUCTION LEFT REAR DOOR LOCK UNIT (IN LEFT REAR DOOR) LOCK NCA WIRE PASSENGER SIDE FRONT DOOR AJAR SWITCH (ON RIGHT "B" PILLAR) PASSENGER SIDE FRONT DOOR LOCK UNIT (IN PASSENGER'S DOOR) PASSENGER SIDE REAR DOOR AJAR SWITCH (ON RIGHT "C" PILLAR) RESET+ RIGHT REAR DOOR LOCK UNIT (IN RIGHT REAR DOOR) SEDAN SET- UNLOCK WAGON WHT/BLK WIRE WHT/GRN WIRE YEL/BLK WIRE YEL/BLK YEL/BLK WIRE
