Ford Focus II (2005-2008) w/ front, rear power windows Wiring diagrams
This page contains all the electrical diagrams for the component. w/ front, rear power windows, in which he is found in the car Ford Focus II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ front, rear power windows (1 of 2)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
CENTRAL JUNCTION BOX (CJB) (BEHIND
CLOCK- SPRING
DRIVER SIDE SEAT HEATER SWITCH
FROM FUSE 1 (DIAGRAM 3 OF 4)
FUSE 42
FUSE 43
FUSE 52
FUSE 53
FUSE 54
FUSE 55
FUSE 56
GRN WIRE
GRN/YEL WIRE
MASTER WINDOW ADJUST SWITCH
MOONROOF ADJUST SWITCH
ONE-TOUCH WINDOW RELAY
ORG/ WIRE
PARK/ NEUTRAL POSITION (PNP) SWITCH (M/T)
PASSENGER SIDE SEAT HEATER SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
REAR WIPER MOTOR ASSEMBLY
REAR WIPER RELAY
RED WIRE
ROOF OPENING PANEL UNIT
STOPLAMP SWITCH
W/ FRONT POWER WINDOWS
W/ FRONT, REAR POWER WINDOWS
W/ ROOF OPENING PANEL
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Power distribution circuit, early production (4 of 4) -> W/ FRONT, REAR POWER WINDOWS
Wiring diagram w/ front, rear power windows (2 of 2)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
CENTRAL JUNCTION BOX (CJB) (BEHIND
CLOCK- SPRING
DRIVER SIDE SEAT HEATER SWITCH
FROM FUSE 1 (DIAGRAM 3 OF 4)
FUSE 42
FUSE 43
FUSE 52
FUSE 53
FUSE 54
FUSE 55
FUSE 56
GRN WIRE
GRN/YEL WIRE
MASTER WINDOW ADJUST SWITCH
MOONROOF ADJUST SWITCH
ONE-TOUCH WINDOW RELAY
ORG/ WIRE
PARK/ NEUTRAL POSITION (PNP) SWITCH (M/T)
PASSENGER SIDE SEAT HEATER SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
REAR WIPER MOTOR ASSEMBLY
REAR WIPER RELAY
RED WIRE
ROOF OPENING PANEL UNIT
STOPLAMP SWITCH
W/ FRONT POWER WINDOWS
W/ FRONT, REAR POWER WINDOWS
W/ ROOF OPENING PANEL
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Power distribution circuit, late production (4 of 4) -> W/ FRONT, REAR POWER WINDOWS
