Ford Focus II (2005-2008) w/ front power windows Wiring diagrams

This page contains all the electrical diagrams for the component. w/ front power windows, in which he is found in the car Ford Focus II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/ front power windows (1 of 2)

Wiring diagram w/ front power windows for Ford Focus II (2005-2008) (1 of 2)

Get access

BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH CENTRAL JUNCTION BOX (CJB) (BEHIND CLOCK- SPRING DRIVER SIDE SEAT HEATER SWITCH FROM FUSE 1 (DIAGRAM 3 OF 4) FUSE 42 FUSE 43 FUSE 52 FUSE 53 FUSE 54 FUSE 55 FUSE 56 GRN WIRE GRN/YEL WIRE MASTER WINDOW ADJUST SWITCH MOONROOF ADJUST SWITCH ONE-TOUCH WINDOW RELAY ORG/ WIRE PARK/ NEUTRAL POSITION (PNP) SWITCH (M/T) PASSENGER SIDE SEAT HEATER SWITCH PASSENGER SIDE WINDOW ADJUST SWITCH REAR WIPER MOTOR ASSEMBLY REAR WIPER RELAY RED WIRE ROOF OPENING PANEL UNIT STOPLAMP SWITCH W/ FRONT POWER WINDOWS W/ FRONT, REAR POWER WINDOWS W/ ROOF OPENING PANEL WHT WIRE WINDSHIELD WIPER MOTOR WINDSHIELD WIPER RELAY WIPER/ WASHER SWITCH YEL WIRE

Go to component -> Power distribution circuit, early production (4 of 4) -> W/ FRONT POWER WINDOWS

Wiring diagram w/ front power windows (2 of 2)

Wiring diagram w/ front power windows for Ford Focus II (2005-2008) (2 of 2)

Get access

Go to component -> Power distribution circuit, late production (4 of 4) -> W/ FRONT POWER WINDOWS

Ford Focus II (2005-2008) w/ front power windows Wiring diagrams

Wiring diagram w/ front power windows (1 of 2)

List of components:

Wiring diagram w/ front power windows (2 of 2)

List of components:
