Ford Focus II (2005-2008) switch illum. Wiring diagram
This page shows the only wiring diagram for the component.switch illum., which is found in the car Ford Focus II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch illum. (1 of 1)
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DEFROST RELAY
FUSE 45
FUSE 50
FUSE 7
GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEATER
HEATER CONTROL MODULE (BEHIND DASH)
HOT AT ALL TIMES
HOT IN START OR RUN
IGNITION SWITCH
LEFT EXTERIOR REAR VIEW MIRROR
LOCK OFF
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
REAR WINDOW
REAR WINDOW HEATER SWITCH
RED WIRE
RIGHT EXTERIOR REAR VIEW MIRROR
RUN WIRE
SWITCH ILLUM.
Go to component -> Heated mirrors circuit -> SWITCH ILLUM.
