Ford Focus II (2005-2008) radio remote control switch Wiring diagram
This page shows the only wiring diagram for the component.radio remote control switch, which is found in the car Ford Focus II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio remote control switch (1 of 1)
1 2 3 4 5 5 6 7 8 AUDIO SIG (+) AUDIO SIG (-) SHIELD AMP ENABLE
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
COAXIAL LEAD
FUSE 11
FUSE 31
FUSE 41
FUSE 62
GRN WIRE
GROUND GROUND
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR ACC
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LF SPEAKER (-) LR SPEAKER (-) RR SPEAKER (-)
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
POWER POWER AUDIO SIG (+) AUDIO SIG (-)
RADIO
RADIO REMOTE CONTROL SWITCH
RED WIRE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
ROOF OPENING PANEL UNIT (AT CENTER FRONT OF ROOF)
SIG RTN
SUBWOOFER
SW EN/ CLIP DETECT 1 2 3 4 5 6 7 8 9 10
VSS
VSS VSS
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Radio circuit -> RADIO REMOTE CONTROL SWITCH
