Ford Focus II (2005-2008) power hold relay fuse 9 wiring diagram
This page shows the only wiring diagram for the component.power hold relay fuse 9, which is found in the car Ford Focus II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
power hold relay fuse 9 wiring diagram (1 of 1)
1 2 3 4 VPWR GND TX RX
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPT)
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FUSE 36
FUSE 61
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
ORG/ WIRE
ORG/BLK WIRE
PASSIVE ANTI-THEFT TRANSCEIVER MODULE
PATS IND
POWER HOLD RELAY FUSE 9
RED WIRE
STARTING/ CHARGING SYSTEM
WHT/GRN WIRE
