Ford Focus II (2005-2008) passenger side seat heater switch Wiring diagrams

This page contains all the electrical diagrams for the component. passenger side seat heater switch, in which he is found in the car Ford Focus II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram passenger side seat heater switch (1 of 4)

Wiring diagram passenger side seat heater switch for Ford Focus II (2005-2008) (1 of 4)

Get access

BLK WIRE BLU WIRE CAMSHAFT POSITION SENSOR SHIELD CRANKSHAFT POSITION SENSOR SHIELD DRIVER SIDE SEAT HEATER SWITCH EARLY PRODUCTION ENGINE COMPT) FUEL PUMP DRIVER MODULE FUEL TANK UNIT SHIELD GEARSHIFT LEVER UNIT GENERIC ELECTRONIC MODULE (GEM) KNOCK SENSOR SHIELD LATE PRODUCTION NCA WIRE ORG/ WIRE PASSENGER SIDE DOOR LOCK SWITCH PASSENGER SIDE FRONT DOOR AJAR SWITCH PASSENGER SIDE FRONT HEATED SEAT ELEMENT PASSENGER SIDE REAR DOOR AJAR SWITCH PASSENGER SIDE SEAT HEATER SWITCH PASSENGER SIDE WINDOW ADJUST SWITCH POWERTRAIN CONTROL MODULE (PCM) REAR WINDOW DEFROST GRID RIGHT EXTERIOR REAR VIEW MIRROR RIGHT REAR LAMP ASSEMBLY RIGHT REVERSING LAMP RIGHT REAR WINDOW ADJUST SWITCH SEAT WEIGHT SENSOR MODULE SEDAN SUBWOOFER AMPLIFIER WAGON

Go to component -> Ground distribution circuit (3 of 4) -> PASSENGER SIDE SEAT HEATER SWITCH

Wiring diagram passenger side seat heater switch (2 of 4)

Wiring diagram passenger side seat heater switch for Ford Focus II (2005-2008) (2 of 4)

Get access

BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH CENTRAL JUNCTION BOX (CJB) (BEHIND CLOCK- SPRING DRIVER SIDE SEAT HEATER SWITCH FROM FUSE 1 (DIAGRAM 3 OF 4) FUSE 42 FUSE 43 FUSE 52 FUSE 53 FUSE 54 FUSE 55 FUSE 56 GRN WIRE GRN/YEL WIRE MASTER WINDOW ADJUST SWITCH MOONROOF ADJUST SWITCH ONE-TOUCH WINDOW RELAY ORG/ WIRE PARK/ NEUTRAL POSITION (PNP) SWITCH (M/T) PASSENGER SIDE SEAT HEATER SWITCH PASSENGER SIDE WINDOW ADJUST SWITCH REAR WIPER MOTOR ASSEMBLY REAR WIPER RELAY RED WIRE ROOF OPENING PANEL UNIT STOPLAMP SWITCH W/ FRONT POWER WINDOWS W/ FRONT, REAR POWER WINDOWS W/ ROOF OPENING PANEL WHT WIRE WINDSHIELD WIPER MOTOR WINDSHIELD WIPER RELAY WIPER/ WASHER SWITCH YEL WIRE

Go to component -> Power distribution circuit, early production (4 of 4) -> PASSENGER SIDE SEAT HEATER SWITCH

Wiring diagram passenger side seat heater switch (3 of 4)

Wiring diagram passenger side seat heater switch for Ford Focus II (2005-2008) (3 of 4)

Get access

Go to component -> Power distribution circuit, late production (4 of 4) -> PASSENGER SIDE SEAT HEATER SWITCH

Wiring diagram passenger side seat heater switch (4 of 4)

Wiring diagram passenger side seat heater switch for Ford Focus II (2005-2008) (4 of 4)

Get access

BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DRIVER SIDE SEAT HEATER SWITCH DRIVER'S SIDE FRONT HEATED SEAT ELEMENT (UNDER DRIVER'S FUSE 52 GRN/BLK WIRE GRN/BLU WIRE GRN/YEL WIRE HOT IN START OR RUN NCA WIRE ON IND. PANEL ILLUMINATION PASSENGER SIDE SEAT HEATER SWITCH PASSENGER'S SIDE FRONT HEATED SEAT ELEMENT (UNDER PASSENGER'S SEAT)

Go to component -> Power seats circuit -> PASSENGER SIDE SEAT HEATER SWITCH

Ford Focus II (2005-2008) passenger side seat heater switch Wiring diagrams

Wiring diagram passenger side seat heater switch (1 of 4)

List of components:

Wiring diagram passenger side seat heater switch (2 of 4)

List of components:

Wiring diagram passenger side seat heater switch (3 of 4)

List of components:

Wiring diagram passenger side seat heater switch (4 of 4)

List of components:
