Ford Focus II (2005-2008) panel illumination Wiring diagram
This page shows the only wiring diagram for the component.panel illumination, which is found in the car Ford Focus II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram panel illumination (1 of 1)
BLK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DRIVER SIDE SEAT HEATER SWITCH
DRIVER'S SIDE FRONT HEATED SEAT ELEMENT (UNDER DRIVER'S
FUSE 52
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HOT IN START OR RUN
NCA WIRE
ON IND.
PANEL ILLUMINATION
PASSENGER SIDE SEAT HEATER SWITCH
PASSENGER'S SIDE FRONT HEATED SEAT ELEMENT (UNDER PASSENGER'S
SEAT)
Go to component -> Power seats circuit -> PANEL ILLUMINATION
