Ford Focus II (2005-2008) off low speed med low Wiring diagram
This page shows the only wiring diagram for the component.off low speed med low, which is found in the car Ford Focus II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off low speed med low (1 of 1)
A/C ON
A/C SWITCH
A/C SWITCH ILLUMINATION
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR RESISTOR (BEHIND CENTER OF DASH)
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DEFOGGER SYSTEM
DEICING SWITCH
FUSE 19
FUSE 36
FUSE 45
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEATER BLOWER MOTOR (BEHIND CENTER OF DASH)
HEATER BLOWER SWITCH
HEATER CONTROL MODULE (BEHIND DASH)
HOT AT ALL TIMES
HOT IN START OR RUN
MED HIGH HIGH
OFF LOW SPEED MED LOW
OFF OFF ON ON
ON OFF OFF
ON ON OFF OFF
ORG/ WIRE
ORG/GRN WIRE
REAR WINDOW HEATER ON
REAR WINDOW HEATER SWITCH
REAR WINDOW HEATER SWITCH ILLUMINATION
RECIRCULATION AIR ACTUATOR (BEHIND RIGHT SIDE OF DASH, NEXT TO BLOWER MOTOR)
RECIRCULATION ON
RECIRCULATION SWITCH
RECIRCULATION SWITCH ILLUMINATION
RED WIRE
SOLID STATE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Manual a/c circuit (1 of 2) -> OFF LOW SPEED MED LOW
