Ford Focus II (2005-2008) low beam relay Wiring diagrams
This page contains all the electrical diagrams for the component. low beam relay, in which he is found in the car Ford Focus II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
low beam relay wiring diagram (1 of 7)
A/C CLUTCH FIELD COIL WINDSHIELD WIPER MOTOR
ABS CONTROL MODULE
BATTERY
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
DAYTIME RUNNING LAMPS (DRL) RELAY
ENGINE COMPARTMENT SWITCH
FUEL PUMP RELAY
GRN WIRE
HIGH BEAM RELAY
HORN
IGNITION RELAY
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT HEADLAMP
LOW BEAM RELAY
MASS AIR FLOW (MAF SENSOR)
ORG/ WIRE
POWER HOLD RELAY
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SECOND COOLING FAN MOTOR
SPEED CONTROL SERVO
VEHICLE SPEED SENSOR (VSS)
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> LOW BEAM RELAY
low beam relay wiring diagram (2 of 7)
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DAYTIME RUNNING LAMPS RELAY
DAYTIME RUNNING LAMPS RESISTOR
FOG LAMPS
FUSE 16
FUSE 17 FUSE 27 FUSE 26
FUSE 22
FUSE 59
GRN WIRE
GRN/BLU WIRE
HIGH BEAM RELAY
HOT AT ALL TIMES
HOT IN START OR RUN
ILLUMINATION
INSTRUMENT CLUSTER HIGH BEAM IND
LEFT FRONT FOG LAMP
LEFT HEAD- LAMP RIGHT HEAD- LAMP HI HI LO
LOW BEAM
LOW BEAM RELAY
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NEUTRAL HIGH FLASH
OFF
OFF LOW BEAM PARK
OFF PARK
ORG/ WIRE
RED WIRE
RIGHT FRONT FOG LAMP
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, early production with drl -> LOW BEAM RELAY
low beam relay wiring diagram (3 of 7)
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FOG LAMPS
FUSE 16
FUSE 17 FUSE 27 FUSE 26
FUSE 59
GRN WIRE
GRN/BLU WIRE
HIGH BEAM RELAY
HOT AT ALL TIMES
HOT IN START OR RUN
ILLUMINATION
INSTRUMENT CLUSTER HIGH BEAM IND
LEFT FRONT FOG LAMP
LEFT HEAD- LAMP RIGHT HEAD- LAMP HI HI LO
LOW BEAM RELAY
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NEUTRAL HIGH FLASH
OFF
OFF LOW BEAM PARK
ORG/ WIRE
RED WIRE
RIGHT FRONT FOG LAMP
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, early production without drl -> LOW BEAM RELAY
low beam relay wiring diagram (4 of 7)
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 59
DAYTIME RUNNING LAMPS RELAY
FOG LAMPS
FUSE 16
FUSE 17
FUSE 22
FUSE 23
FUSE 44
GRN WIRE
GRN/BLU WIRE
HI LO
HIGH BEAM IND
HIGH BEAM RELAY
HOT AT ALL TIMES
HOT IN START OR RUN
ILLUMINATION
INSTRUMENT CLUSTER
LEFT FRONT FOG LAMP
LEFT HEAD- LAMP
LO HI
LOW BEAM
LOW BEAM RELAY
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NEUTRAL FLASH
NEUTRAL HIGH FLASH
OFF LOW BEAM
OFF OFF PARK
ORG/ WIRE
PARK
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEAD- LAMP
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, late production with drl -> LOW BEAM RELAY
low beam relay wiring diagram (5 of 7)
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FOG LAMPS
FUSE 16
FUSE 17
FUSE 22
FUSE 23
FUSE 59
GRN WIRE
GRN/BLU WIRE
HI LO
HIGH BEAM IND
HIGH BEAM RELAY
HOT AT ALL TIMES
HOT IN START OR RUN
ILLUMINATION
INSTRUMENT CLUSTER
LEFT FRONT FOG LAMP
LEFT HEAD- LAMP
LO HI
LOW BEAM RELAY
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NEUTRAL FLASH
OFF
OFF LOW BEAM PARK
ORG/ WIRE
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEAD- LAMP
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, late production without drl -> LOW BEAM RELAY
low beam relay wiring diagram (6 of 7)
14 1 (W/O TCS) (W/ TCS)
20 4 (W/O TCS) (W/ TCS)
ABS CONTROL MODULE
BLK WIRE
BLU WIRE
CORNER OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB)
ENGINE COOLING FAN RELAY
FROM BATTERY (DIAGRAM 1 OF 4)
FROM FUSE 6 (DIAGRAM 1 OF 4)
FROM FUSE 9 (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (DIAGRAM 2 OF 4)
FUSE 1
FUSE 19 FUSE 15
FUSE 24
FUSE 29
GRN WIRE
GRY WIRE
HEATER BLOWER MOTOR
HIGH BEAM RELAY
HIGH SPEED FAN CONTROL RELAY
IDLE AIR CONTROL (IAC) VALVE
IGNITION RELAY
LOW BEAM RELAY
ORG/ WIRE
OTHERS
PCM POWER DIODE
POWER HOLD RELAY
POWERTRAIN CONTROL MODULE
RED WIRE
SIDE OF ENGINE COMPT)
SPEED CONTROL MODULE
TO FUSE 53 (DIAGRAM 4 OF 4)
W/ SPEED CONTROL OR ABS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, early production (3 of 4) -> LOW BEAM RELAY
low beam relay wiring diagram (7 of 7)
A/C CLUTCH RELAY
ABS CONTROL MODULE
BATTERY
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPT)
BATTERY SAVER RELAY
BLK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (DLC)
FRONT CIGAR LIGHTER
FUEL AIR PUMP PUMP RELAY RELAY
FUSE 20 FUSE 12
FUSE 21
FUSE 22
FUSE 23
FUSE 30
FUSE 31
FUSE 32 FUSE 63
FUSE 33 FUSE 48
FUSE 34
FUSE 35 FUSE 36
FUSE 4
FUSE 47
FUSE 5 FUSE 13
FUSE 6 FUSE 9 FUSE 7
FUSE 8
FUSE FUSE 11
GENERIC ELECTRONIC MODULE (GEM)
GRN WIRE
HEATER CONTROL MODULE
HIGH BEAM RELAY
HORN RELAY
IN-LINE FUSE
INSTRUMENT CLUSTER
LOW BEAM RELAY
MAIN LIGHT SWITCH
ORG/ WIRE
POWERTRAIN CONTROL MODULE
RADIO
REAR WINDOW DEFROST RELAY
RED WIRE
ROOF OPENING PANEL UNIT
STARTER MOTOR
STARTER RELAY
SUBWOOFER GENERATOR AMPLIFIER
TO IGNITION RELAY (DIAGRAM 3 OF 4)
TO IGNITION SWITCH (DIAGRAM 2 OF 4)
TO POWER HOLD RELAY (DIAGRAM 3 OF 4)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, late production (1 of 4) -> LOW BEAM RELAY
